Sample 7162#

截面的艺术：当较厚的AAO膜斜向断裂时产生独特的截面结构

The Art of the Cross-section: the special cross-sectional morphology of AAO

截面的艺术：当较厚的AAO膜不规则断裂时产生独特的截面结构

The Art of the Cross-section: the special cross-sectional morphology of AAO

铝的两面同时电解，当铝被全部消耗时，界面的形貌

The interface morphology of two-layer AAO films anodized from the both sides of high purity aluminum foils

树枝状孔道结构：一般的AAO孔道都是相互平行，并且垂直于样品表面。这种独特的树枝状结构可以通过不稳定的电解过程获得。

Generally, the AAO nanopres are parallel to each other, and vertical to the sample surface. This special branch-like structure can be obtained through un-stable anodization.

树枝状孔道结构：一般的AAO孔道都是相互平行，并且垂直于样品表面。这种独特的树枝状结构可以通过不稳定的电解过程获得。

Generally, the AAO nanopres are parallel to each other, and vertical to the sample surface. This special branch-like structure can be obtained through un-stable anodization.

7172

2009-7-24 0:202009-7-24 0:20

2010-9-7 15:06

树枝状孔道结构：一般的AAO孔道都是相互平行，并且垂直于样品表面。这种独特的树枝状结构可以通过不稳定的电解过程获得。

Generally, the AAO nanopres are parallel to each other, and vertical to the sample surface. This special branch-like structure can be obtained through un-stable anodization.

Sample 7175 #

树枝状孔道结构：一般的AAO孔道都是相互平行，并且垂直于样品表面。这种独特的树枝状结构可以通过不稳定的电解过程获得。

Generally, the AAO nanopres are parallel to each other, and vertical to the sample surface. This special branch-like structure can be obtained through un-stable anodization.

Sample 7179#

这是去除AAO之后的铝表面，我们也不知道为什么有这样的结果

This is the aluminum surface after removing AAO, and we also don’t know how this structure comes into being.

Sample 7221#

Sample 10295#

Sample 10302#

Sample 10302#

2011-12-7 ZEISS PAA Sample 1-10

Sample 2012-6-21 10#， 是否像小鸡要破壳而出？
